The direct-cooled Chiller is connected to the customer-side evaporator by piping, using the phase change of the refrigerant to absorb heat and cool the evaporator. Compared with liquid cooling, it has the advantage of greater heat flow density and is suitable for applications where a larger heat exchange volume can be achieved in a small volume.
The direct-cooled Chiller is connected to the customer-side evaporator by piping, using the phase change of the refrigerant to absorb heat and cool the evaporator. Compared with liquid cooling, it has the advantage of greater heat flow density and is suitable for applications where a larger heat exchange volume can be achieved in a small volume.
| Item | Unit | ACSM02D-40 | ACSM03D-40 | ACSM05D-40 | ACSM10D-40 | ACSM15D-40 |
| cooling capacity(-40℃) | kW | 0.9 | 1.2 | 2.1 | 4.2 | 5.6 |
| Compressor power | kW | 2.6 | 2.9 | 5.0 | 8.2 | 14.0 |
| Operating current | A | 5.2 | 5.8 | 10.0 | 16.4 | 28.0 |
| Power supply | 3PH～380V～50Hz（Customisable 220V） | |||||
| Circulation medium | R404A、R507C | |||||
| Temperature control range | ℃ | -40～-15 | ||||
| Temperature control accuracy | ℃ | ±1 | ||||
| Compressor type | Totally enclosed scroll type/semi-enclosed piston type | |||||
| A throttle | expansion valve | |||||
| operating method | Colour LCD touch screen | |||||
| safety device | Power reverse phase, motor overload, high and low voltage, over temperature protection, etc. | |||||
| communication method | Rs485，Modbus RTU | |||||
